Description

Features:

• Wet Location Rated for Indoor and Outdoor Use (Under covered ceilings)
  Same LED light engine for 850 and 1100 lumens (see housings)
• UL Listed for Direct Contact with insulation
• Standard with 38° beam. Field Changeable optics for 28° (EP716C) and 60° (EP718C)
• CAT24, JA8-2016-E and Energy Star Listed
• Life Span 50,000 Hours L70
• U.S. Pat. 10,125,959

SPECIFICATIONS :

• Wattage 8.6 – 10.5W
• Lumens 850 – 1100 lm
• Color Temp. 2700K – 4000K
• Lamp Type LED
• Beam Angle 38°
• CRI 93+
• Wet Location Listed

Optics: Standard with 38° beam. Field changeable optics for 28° (EP716C) and 60° (EP718C)

Construction: Diecast construction for lasting quality and greater heat dissipation. High quality powder coat finish preventing rust and paint cracking.

Installation: All Teak LED Light Engines feature a trigger release clip that will depress as the module is being inserted, holding the module in place. Hole cutout size: 2-5/8″ (68 mm)

LED Technology:
Extremely accurate color rendering with 93+ CRI.
Efficacy of max. 97 lumens per watt.
Lumen Maintenance of 50,000 hours L70 based on LM80 standardized test results.
Superior Thermal Management by utilizing aluminum body as heat sink.

Electrical: Low voltage input. Requires compatible power supply.

Dimming: Works with Triac/ELV type dimmers when powered by 120V driver. Works with 0-10V/Triac/ELV dimmers when powered by 120/277V driver.

Listings: UL Listed for Wet Location. UL Listed for Direct Contact with insulation. ENERGY STAR® Listed.
California Title 24 (JA8-2016-E).

Warranty: ELCO Products are built to last with a 5-year Limited warranty.
