Description

Details of the Nora Lighting NPTCB-E24L40/30AW 2×4 LED Center Basket Troffer, 4000L, 3000K, White

Energy-efficient and economical Center Basket LED Troffer produces an incredible amount of smooth and uniform general lighting. Fixtures are 120V/277V with 0“10V dimming, are available in a range of Kelvin temperatures and are DLC listed. The fixtures include a diffused, removable lens, a hinged access plate with LED board and built-in earthquake clips. The shallow housing design and easy access wiring plate make the Center Basket Troffer a quick installation. Ideal for use in task areas where general illumination is desired such as offices, schools, conference rooms, libraries, retail, hospitals and others.

Features

• Architectural style and quality
• Complete room illumination
• 4000lm / 36W or 6100lm / 44W
• 3000K, 3500K, 4000K or 5000K Color Temperatures
• Soft, uniform reflectance
• Fits most grid ceilings
• Removeable diffused lens evenly distributes light and maximizes performance
• Two replaceable LED Strips with tightly spaced diodes eliminate diode image
• Enclosed driver compartment easily accessible from below via hinged LED platform
• Built-in earthquake clips
• Dimmable with compatible 0-10V dimmer
• 100-277V
• cULus Damp Location Listed
• DLC listed

Specification

• Brand: Nora Lighting
• SKU: NPTCB-E24L40/30AW
• UPC: 732180009756
• Product Line: LE57
• Product Family: Center Basket Troffer
• Product Type: Troffer
• Color Temperature: 3000K
• Wattage: 37W
• Lumens: 4000lm
• CRI: 85
• Product Dimensions (W x H x L): 24 x 4 x 48
• Finish Color: White
• Product Weight (lb): 16.15

Downloads

Specification Sheet Sales Sheet IES File Instruction Sheet

Photometric Layout
