Technical Specs

• Voltage: 100-277V AC 50/60Hz
• Wattage: 90W/120W/150W
• Power Factor: 0.95
• Efficacy: 150LM/W
• Aluminum Housing , Outdoor Powder Coated
• Twin (Double) Arm Fits On 2-3/4� Poles
• For 2-3/8� OD Pole/Pipe
• Programmable Bi-Level Motion Sensor Emergency Backup Options
• Operating Temperature: -86F~122F
• IP Rating: IP66, Suitable for Wet Locations
• 7-Year Warranty
• Multi CCT and Power: Selectable Switch Inside Of The Fixture
• Dimmable: 0~10V Dimming
• LED: SMD 3030
• Total Lumens: 22500LM Max.
• Color Temperature: 3000K/4000K/5000K
• Color Rendering index: 70
• Beam Angle: Type V (150 X 150)
• Lifespan: 70000 Hrs.

Applications

• Ideal for gardens, amusement parks, residential quarters, industrial parks, and pedestrian streets.
