Description

Technical Specs

• Voltage: 120V AC 50Hz
• Wattage: 30W
• Power Factor: 0.95
• Total Harmonic Distortion: % 20 %
• Efficacy: 70 LPW
• On/Off: short press the touch button to turn on or off the light and relay at the same time
• Color temperature adjustment: When the light is on, short press the touch button to switch the color temperature, and the settings will be stored in the memory
• Dimming: when the light is on, long press (hold) the touch button to adjust the brightness, stepless non-cyclic adjustment of light brightness
• Finish: Aluminium Frame
• Frontlit (Bar Pattern)
• Touch Sensor Switch
• Demister Pad
• IP44, Indoor Use only
• Operating Temperature: -22F to 104F
• 5-Year Warranty
• Multi-CCT: Brightness CCT Touch Buttons Located on The Mirror
• Total Lumens: 2100LM
• Color Temperatures: 3000K/4500K/6500K
• Color Rendering Index: CRI %90
• 50,000 Hours Rated Life

Applications

• LED Mirrors And Cabinet Dimming With Defogger Feature Ideal for Office, Retail Store, Showroom, Residential Applications and Damp Environment Lighting Applications
