Description

Technical Specs

• Voltage: 24VDC (LED driver required)
• Wattage: 4.4W per ft.
• Max Run: 20ft.
• Efficacy: 75~79LM/W per ft.
• Cutting increment: Every 4 inches
• 3M double sided tape(9474LE) is preinstalled
• Includes 1 female ribbon-to-power supply connector (Prewired) and 1 male plug for connection to next ribbon (Prewired)
• IP rating: IP20
• Dimming: Dimmable using a magnetic driver
• LED: SMD2835 chip spaced 5/8� on center, 19 per foot, 0.23 wats each chip
• LED Type: SMD2835
• Total lumens: 310~350LM per ft.
• Color temperature: 3500K
• Color rendering index: 90
• Beam Angle: 120

Applications

• Ideal for undercabinet, soffit, display cases and toe kick lighting.

Download PDF File

Specification
