Description

Technical Specs

• Input Wattage: 25W-150W
• Input Voltage: 120-277V AC 50/60Hz
• Input Current: 1.0 A
• Power Factor: 0.9
• Efficacy: 140 LPW
• ADC12 Aluminum Heat Sink, Outdoor Powder Coating
• Lens: Prismatic Borosilicate Glass Lens
• Same Footprint as Traditional HID Wall Packs
• DC Button Photocell with ON/OFF Switch Included
• Four 1/2″ Hubs: 1 Top, 1 on Each Side, 1 Rear
• Mounting: Wall Mounting
• Operating Temperature: -40F ~ 104F
• IP67 Stainless Steel Test Button with Integrated Indicator Light, Wet Locations
• Dimming: 0-10V Dimming
• Multi-Power Switch is Inside the Fixture
• Total Lumens: 9100LM-21000LM
• Color Temperature: 3000K/4000K/5000K
• 8W, 48V, 2500mAh Li-ion Battery for Minimum 90 Minutes Emergency Operation
• CRI: 70
• Lifespan: 70000 Hrs

Applications

• Ideal for general site lighting, alleys, loading docks, doorways, pathways, and parking areas.
• Replace existing HID wall packs
• Great for use with photocell
