Description

Technical Specs

• :: Voltage: 120-277VAC 60Hz
• :: Wattage: 24W/32W/40W
• :: Power Factor: 0.95
• :: Efficacy: 135 LPW
• :: Die-Cast Aluminum With Powder Coat Finish (Dark Bronze)
• :: High Light Transmittance, Anti-UV and Fire Resistant Shatterproof PC Lens
• :: Operating Temperature: -4F to 104F
• :: Full Cutoff, Dark Sky Compliant
• :: IP 65,Wet Location
• :: 7-Year Warranty
• :: Dimming: 0~10V Dimmable
• :: Multi CCT and Power (Switches are inside fixture)
• :: The Type III Distribution Is Used for Wide WalkWays, on Ramps and Entrance Roadways, As Well As Other Long, Narrow Lighting
• :: Total Lumens: 5400LM Max.
• :: Color Temperatures: 3000K/4000K/5000K
• :: Color Rendering Index: CRI š¬° 80
• :: Rated Life: 70,000 Hrs

  Applications

• :: LED Wall Pack Light series can be widely used as Exterior or Interior LED lighting for Hotels, Garages, Commercial Buildings, Public areas, Schools and Hospitals, etc.
